  1. Checking the rear diff and front ptu oil levels are a good idea. Signs of leaks, dark stains just below driveshaft or c/v shaft locations makes it even more important. Front ptu has no dipstick to check level. Dump and fill will tell you amount of 75w90 that was there. Full is only around 700-800 milli litres. Rear diff has side plug for level gauge, holds around 1.3 litre I believe. Look for signs of metal in any oil dumped from transfer cases. Grinding noise could be related to brake work done, you need to investigate more.
  2. Welcome to the site orthotec28 , not trying to be harsh. No capital letters being used in discussion. ? I think it’s either Borg Warner or Getrag designed system; decent oem suppliers for years. Sometimes there are weak links for reliability on a vehicle that deserve updating. But even F150:trucks are using one piece unserviceable driveshafts units on some models. It’s the direction automotive has been moving for a while; throwaway not rebuildable. If you were going to go off road a bit and wanted a switchable a system that stayed in awd for a period of time. It would necessitate large changes to the factory system. A custom 4x4 builder could for a ton of money probably do something. But the driveshaft shaft and transfer cases are really tucked in underneath, a major lift and would also be needed. Switching vehicles a better option imo.
  3. Why. It’s a simple maint free part time system. You cant add any performance modifying it. It’s a balanced high speed turning driveshaft assembly with sealed connections and a single hangar bearing. My wife’s is still functioning at 225k kilometres or 140k miles and hasn’t been touched. Very pricy to replace if it does go, oem is around $600 I believe. My Jeep’s with double cardigan and ujoints, multiple grease fittings needed way more maint, but they were designed for continuous use and had a lot more torque on them. The Journey system is simple and fairly reliable if you keep a close eye on the oil level in the ptu and rear diff systems. Run them out of oil from a lip seal leak and you have a very expensive repair.
  4. If you search in the site, you will find not really. How many miles on engine ? You can remove surpentine belt and run car for 10 seconds, careful, no water pump flow like this. This takes, everything external that spins out of the mix. If still a noise it is internal like timing belt tensioner or roller follower, valve lifter etc. Water pump bearings can knock when they start to fail; but usually lip seal on front starts to leak, or weap hole shows signs. A high milage kinda fIx usually. Engine stethoscope can pick that up the noise. If you are going to a shop and you have to explain how to trouble shoot….you are at the wrong place.
  5. Led load resisters needed on the circuit, or as OP’s are saying, buy better bulbs. https://www.rockauto.com/en/tools/electrical-bulb+&+socket,tool,led+bulb+load+equalizer,49474
  6. You need to disable traction control when you get stuck. It allows a bit of wheel spin for getting out. You can’t spin the wheels for long periods of time without overheating transmission very quickly. Try unhooking battery for a few minutes to see remote possibility it’s just stuck in limp mode. A code reader that can access transmission codes is needed to see what parts could be damaged. Torque converter, pump, fluid body etc. It may not be the first time the car has been in the rhubarb; automatic transmissions can be fragile.
  7. If vehicle originally had a functioning dealer camera already already, the code would have been installed. You are correct the part number is wrong, here is a Canadian oem part link. https://parts.motorcitychrysler.ca/p/Park-Assist-Camera-Rear/74170856/56054158AG.html I think real issue could be firmware in the new oem camera reacting to the Apple car play aftermarket interface unit you added. Electronics sometimes don’t play nice when copy write stuff is involved. Not much plug and play in the proprietary automotive world. I would try a generic aftermarket cam mounted in place of the factory cam. Try for higher IP68 I think water rating and best pixel rating you can find. Alpine aftermarket cams someone said are not bad, around $95 ish.
  8. Not sure if you seen this. Guy has 10 utube links for left head, quite detailed. Mopar dealer mechanic, 5-6 show chain marking and removal. Vehicle is a minivan with 3.6.
  9. Lots of car parts are hard to get right now with all the supply chain disruptions. As I’m sure you know the head bolts are stretch bolts or t-t-y torque to yield design; Rockauto has them for as little as $30 for Mahle a good brand. Some times it’s the little details that can get you. With the low milage a head swap should be the better option over a wrecker motor IMO.
  10. Link is not working for specs. Canbus electrical systems can act up with added LED lights, create hyper flashing etc. You need a well designed system to avoid issues. I would buy a tube of clear silicone, remove both lights, dry with a hair dryer, then apply silicone where clear lens joins black housing. At 2019 car might be new enough to try for warranty coverage, the headlights are not cheap to buy.
  11. Bottom view here. Could be another fastener, can you study the reman head going on.
  12. I have never removed a Journey cylinder head. Man that’s a big job. Here is a few pics of a left reman head, hope it helps maybe. You need it for recore I assume, needs to be in good shape. Tapping with a brass mallet on a beefy spot might separate gasket from head. Stuff can get welded together by the heat. Use a good torque wrench on the reassembly.
  13. Could you leave ignition on with a charger attatched to battery, instead of running engine. Not in drive but parking brake on.
  14. Welcome to forum. Try TIPM (computer) reset by disconnecting the DJs battery at the negative jumpstart connection for 10-20 minutes.
  15. Just shine a bright flash light down the bracket pin holes. One will be just a straight bored hole, the other will have a larger opening at bottom for the rubber bushing to fit. I think they are at the top hole.
  16. Welcome to the site. Some keys have a security code. I’m assuming your mechanic thinks the code is no longer getting picked up by ignition and ecm computer in car. So fuel pump or power to spark plugs etc don’t work. Is car turning over and trying to start, is there a click noise from starter, can you hear fuel pump at back of car cycle on and pressurize system.? Has he jumpered 85/87 starter relay contacts to prove starter will spin, this bypasses all safety interlocks on car. New keys would be programmed to sinc with car security system which is linked and sometimes integrated into cars main computer or ecm. Physical match of mechanical key and cutting blank is easy. Sometimes there are aftermarket shops who can program new key blanks; but car would need to be there to plug into car electrical system, as far as I know. Not easy to bypass modern key security systems.
  17. Someone needs a slap. ?. Scroll to comment s section, lots of people completely disagree with him. https://jalopnik.com/111-weirdos-have-bought-a-dodge-journey-so-far-this-yea-1848757621
  18. Yeah fuel is nuts up here too. . You are thinking custom tune. I was thinking generic performance boost …they send you a preloaded plug and play ecm. So many 3.6 on the road in Jeep’s and Chargers, there must be something around. Cost, I have no idea, just throwing it out there. I think a custom tune is more suitable to heavy engine, cam etc mods.
  19. I had the first year of the V8 in the Grand Cherokee with a performance tweaked ecm in it. Original owner put in himself,I don’t recall what he said it cost. If you have to deal with state emission testing, that could be a hazzel as well.
  20. Hello welcome to the site. You must look after your cars. Which drive line is it.
  21. Doors that have also have manual access lock actuator much easier to magyver open with their metal arm. This latch is cable only coming from handle. I would study the latch pics below and try using a piece of wire or coat hanger to try hooking latch pivot directly.
  22. The bottom and side pans are quite thick material. If you search here, no one on this site it seems have had to replace the side/ front covers. You could likely sand the metal, put a few coats of primer and then a top coat or two. I’ve done that to the engine oil pan on my wife’s 3.6. They get really rusty and you could lose your engine if you miss the leak for too long. Rockauto, the biggest on line site has no listing , only for the bottom pan. They seem to list most volume failure items; I don’t have any affiliation with them, just a customer. If you don’t have time or have garage access, you could take two fingers of grease and smear a very thin film over the entire pan service. Rub it in really well. Wipe off as much loose paint and dirt as you can before starting. Or buy a can of generic automotive rust control spray and use it. They are environmentally friendly, usually wool oil and other biodegradable stuff. Spray your new power steering cooler lines as well. You must be in the rust belt, like I am. I wouldn’t attempt to replace the cover, my 2 cents.
  23. Welcome to the site. Always room for another car guy!!! 10D36773-657F-497B-B2F3-FF2196BB8AF4.webp
  24. So you used a group 26 with 540 ish cca instead of a group 86 with 640 cca , cold cranking amps capacity. If this was such a mismatch why could your starter motor the highest drawing item on car function, approx 200-300 amps on a cold day. The main fuse on the battery positive terminal feeding the pim, and fuse boxes is around 125 amps, why didn’t that blow. There are all kinds of fuses that would blow if you are drawing too much amperage. They are there to protect components and prevent fires from overheated heated wiring and components. If the battery is not getting charged enough there is a clear dash warning and a code is stored. Negative terminal has a fancy temperature sensor which will see this problem. It often gets shorted with bad boosting polarity mix up. Dealer was able to show you these stored codes ??? Would your alternator work its ass off and have accelerated wear, yes. New battery work harder with a shortened life, yes. Would car maybe not start on a really cold day if lots of short trips with all accessories running; yeah good chance with battery not recovering from enough charging. A slightly undersized battery damaged two critical components in your car with a short ; the fuses didn’t prevent this. Nope; highly highly unlikely. Now if you had a bad boosting incident and melted some charging cables; mmm that’s a different story. Lots of weird damage happens this way, by accident. Fuse can’t always go fast enough.
  25. I did more checking, this thing had me curious. I’ve driven a 305 hp ram and the 283 Journey. It turns out the exhaust manifolds built into the cylinder heads are the same, so are injectors and throttle body intake. The extra power is only from a tune it looks like.; and maybe less restrictive exhaust; which you already have covered. A low budget mod if you are interested.
×
×
